Everpure High Flow CSR Triple Manifold with 10" Prefilter (EV929403)
The Everpure High Flow CSR Triple Manifold with 10" Prefilter is a commercial-grade filtration system designed for combination applications including fountain beverages, coffee, tea, and ice machines, featuring quick-change cartridge technology, built-in pressure monitoring, and an integrated particulate prefilter with Scalestick for reliable equipment protection and scale reduction.
Performance & Specifications
| Feature | Specification |
|---|---|
| Model Number | EV929403 |
| Number of Filters | 5 (3 Main + 1 Prefilter + 1 Scalestick) |
| Inlet Connection | 3/4" FNPT |
| Outlet Connection | 3/4" FNPT |
| Pressure Requirements | 10-125 psi (0.7-8.6 bar), non-shock |
| Temperature Range | 35-100°F (2-38°C) |
Key Features
- ✓ Quick-Change Cartridge Design: Built-in water shut-off and flushing valve enables fast, tool-free cartridge replacements without system shutdown
- ✓ Built-In Pressure Monitoring: Integrated water pressure gauge provides real-time monitoring to help maintain optimal flow and system performance
- ✓ Commercial-Grade Construction: Engineered with corrosion-resistant hardware for exceptional durability, strength, and longevity in demanding foodservice environments
- ✓ Integrated Scale Protection: Includes Everpure Scalestick to minimize scale formation and extend equipment life, reducing maintenance costs
- ✓ Modular Installation System: Mounting box bracket with modular design allows for easy installation and future retrofitting of add-on components without disassembly
- ✓ NSF-Certified Components: All wetted parts have successfully passed NSF extraction tests, ensuring safe drinking water contact materials
FAQ
Q: What applications is the High Flow CSR Triple Manifold designed for?
A: The EV929403 is specifically designed for combination foodservice applications including fountain beverage dispensers, coffee and tea brewers, ice machines, and whole-store filtration needs. Its triple manifold configuration with prefilter provides versatile filtration for multiple equipment types simultaneously.
Q: How much clearance is needed for cartridge replacement?
A: The system requires a minimum of 2.5 inches (6.35 cm) of clearance below the cartridge for easy removal and replacement. The manifold should be installed vertically with cartridges hanging downward for proper operation.
Q: What replacement cartridges are compatible with this manifold?
A: The EV929403 accepts Everpure quick-change cartridges including the EC110 prefilter cartridge (EV9534-12 sold in 12-packs) and SS-IMF cartridge (EV9799-32) for coffee applications, providing flexibility for various water quality needs.
What's Included
- High Flow CSR Triple Manifold system
- Everpure EC110 prefilter cartridge (10")
- Everpure Scalestick
- Mounting box bracket and installation screws
- Built-in water pressure gauge
Note: Only use this system with water that is known to be safe. If the water quality is uncertain, ensure it is disinfected before or after filtration.
