Everpure High Flow CSR Quad Manifold with 20" Prefilter (EV929424)
The Everpure EV929424 High Flow CSR Quad Manifold delivers commercial-grade water filtration for combination applications including fountain beverages, coffee, tea, and ice machines, featuring a 20" prefilter, six filter positions, built-in pressure gauge, and corrosion-resistant construction engineered for durability and longevity in high-demand foodservice environments.
Performance & Specifications
| Feature | Specification |
|---|---|
| Model Number | EV929424 |
| Number of Filters | 6 Filter Positions |
| Prefilter Size | 20 Inch |
| Inlet Connection | 3/4" FNPT |
| Outlet Connection | 3/4" FNPT |
Key Features
- ā Six Filter Positions: Accommodates multiple Everpure quick-change cartridges for comprehensive whole-store filtration coverage
- ā Built-In Water Shut-Off & Flushing Valve: Enables easy, mess-free cartridge changeouts without shutting down entire system
- ā Integrated Pressure Gauge: Monitors water pressure in real-time to ensure optimal flow and performance
- ā 20" EC210 Prefilter & ScaleStick Included: Reduces sediment and helps minimize scale formation to protect downstream equipment
- ā Corrosion-Resistant Construction: All wetted parts pass NSF extraction tests for safety and long-lasting durability
- ā Modular Box Bracket Design: Allows for future retrofitting and add-on components without system disassembly
FAQ
Q: What applications is the EV929424 manifold best suited for?
A: The EV929424 is designed for high-demand commercial applications including fountain beverage dispensers, coffee and tea brewing equipment, ice machines, and whole-store water filtration where multiple water sources need treatment.
Q: What replacement cartridges are compatible with this manifold?
A: The manifold uses Everpure quick-change cartridges including the EC210 prefilter cartridge (EV9534-26 - 6 pack) and SS-IMF cartridge (EV9799-32), designed for easy installation with the cartridge nesting feature.
Q: How much clearance is needed below the manifold for cartridge replacement?
A: The system requires 2.5 inches (6.35 cm) of clearance below the cartridge for easy removal and replacement during routine maintenance.
What's Included
- High Flow CSR Quad Manifold System with 6 Filter Positions
- 20" Everpure EC210 Prefilter Cartridge
- Everpure ScaleStick
- Mounting Box Bracket and Screws
- Built-in Water Pressure Gauge
Note: Only use this system with water that is known to be safe. If the water quality is uncertain, ensure it is disinfected before or after filtration.
