Everpure Endurance High Flow Quad (EV943732) Water Filtration System
The Pentair Everpure Endurance High Flow Quad (EV943732) is a commercial-grade water filtration system engineered for high-volume fountain and combination applications, featuring exclusive precoat filtration technology that reduces chlorine taste and odor while filtering particles as small as 0.2 microns to deliver optimal equipment performance and consistently great-tasting beverages.
Performance & Specifications
| Feature | Specification |
|---|---|
| Model Number | Endurance High Flow Quad (EV943732) |
| Filtration Capacity | 200,000 gallons or 1 year |
| Number of Filters | 4 SEN cartridges + 1 HFUF pretreatment + 1 2SR-BW scale inhibitor |
| Flow Rate | 15 GPM (56.8 LPM) |
| Micron Rating | 0.2 microns |
| Contaminants Filtered | Chlorine taste & odor, dirt, sediment, cysts (Cryptosporidium & Giardia) |
Key Features
- ā High-Capacity Filtration: Treats up to 200,000 gallons per cartridge change cycle, ideal for high-volume commercial operations
- ā Multi-Stage Filtration System: Combines Hollow Fiber Ultrafilter pretreatment, four fine filter cartridges, and scale inhibiting technology
- ā NSF/ANSI Certified: Meets Standards 42 and 53 for contaminant reduction including cyst removal by mechanical means
- ā Micro-Pure II Technology: Proprietary filtration media effectively inhibits bacterial growth on filter media to maximize product life
- ā Built-In Scale Reduction: 2SR-BW cartridge protects equipment from mineral buildup and extends operational lifespan
- ā Easy Monitoring & Maintenance: Integrated pressure gauge provides visual indication of filter status and when cartridge changes are needed
FAQ
Q: How often do the cartridges need to be replaced on the EV943732 system?
A: All filter cartridges should be replaced annually, when the 200,000-gallon capacity is reached, or when water pressure or flow becomes inadequate. All cartridges on the system should be changed at the same time for optimal performance.
Q: What is the operating weight of the Endurance High Flow Quad system?
A: When filled with water, the EV943732 Quad system weighs approximately 69.1 lbs (31.3 kg). Ensure mounting surfaces can support this weight and use adequate wall anchors into solid structure.
Q: Can the pretreatment housing be installed separately from the main unit?
A: Yes, the large pretreatment cartridge can be removed from the main bracket and mounted separately up to 25 feet away using opaque 3/4" beverage tubing with clamps at each end.
What's Included
- Manifold with mounting bracket
- Shroud
- 1 Pleated Endurance HF pretreatment cartridge
- Pretreatment housing
- 4 SEN filter cartridges
- 1 2SR-BW scale inhibitor cartridge
- Housing wrench
- Pressure gauge
Note: Only use this system with water that is known to be safe. If the water quality is uncertain, ensure it is disinfected before or after filtration.
