Panasonic WhisperGreen Select models FV-0511VKL3, FV-0511VKSL3, and FV-1115VKL3 are ultra-quiet, energy-efficient bathroom fans with integrated LED lighting and Pick-A-Flow™ technology. Designed for flexibility, they offer adjustable airflow and low-noise operation, making them ideal for small to large bathrooms.
Increased Energy Efficiency – Panasonic’s superior performance of 0.5” exceeds industry standard set by ASHRAE and ENERGY STAR
Expanded True Flow Performance – The only residential ventfan series with a combination of certified CFM performance at 0.5 w.g. and low sone levels
WiFi Control Module – Enables two-way communication between our ventilation products. Use this with a standalone fan or combine with an Indoor Air Quality healthy home system
Designer Grille Options – Sharper, cleaner lines on the traditional grille
FV-0511VKL3 - 50-80-110 CFM 4" or 6" Duct
FV-0511VKSL3 - 30 to 110 CFM 4" or 6" Duct
FV-1115VKL3 - 110-130-150 CFM 6" Duct
Installation:
A licensed electrician is recommended for all installation work.
Turn off power at the breaker before beginning to ensure safety.
Mount the fan using the Flex-Z Fast bracket between ceiling joists for easy positioning.
Connect the appropriate exhaust duct—4" for FV-0511 models or 6" for FV-1115—then seal the connection with foil tape or mastic to prevent air leakage.
Wire the fan according to your preferred setup, whether using a standard wall switch or multi-speed control.
Once wired, secure the fan housing so it sits flush with the ceiling, then attach the grille by compressing the spring clips and snapping it into place.
Restore power and test both the fan and LED lighting to ensure everything is working properly.
